Re: coolant flow - (follow up to cooling diagram)

Post by Ron Miel » Thu Nov 18, 2010 10:08 am

Northern Bongolow wrote:well done steve =D> =D> =D> =D> =D> :lol: for all your hard work.i must just say,that in my humble opinion,i hasnt really pointed to a head design fault. or has it.
to me it just points to looking after your cooling system properly.i know you cannot help what you inherit.maybe bongo's that come up for sale should come with a certified cooling system,with x rays to prove. :shock: :lol:
Surely it's a question of degree, if not semantics. Room for design improvement, anyway - hence the 2001 head re-design for other applications of this Ford engine?

I think the whole thread does still point up the benefits of using the full Mazda-specified air bleed procedure for re-filling after any drain down which introduces air into the upper levels of the system - even though, with luck, a following wind, a good fast reacting coolant temperature monitor, and very careful attention, the engine idling/self-bleeding/automatic de-gassing method can also be made to work. Whether every time is another matter, and I reckon the jury's out, unless a lot more peeps are persuaded to try it first - I wouldn't, particularly not in my V6 (see below).

The coolant flows highlighted here http://www.igmaynard.co.uk/bongo/forum/ ... 02#p457197 confirm, once again, that the front heater is particularly tricky to bleed. Routing of coolant from there, through a switchback of plumbing before it eventually gets round to the expansion/de-gassing tank (as it really is) means that trapped air in the heater will be particularly slow to fully shift by transfer to the ex tank for eventual venting by topping up there - unless the high revving Mazda method is used.

These observations are based on recent direct experience, as well as a number of PM exchanges with two other peeps with related experience, careful reading of this brilliant topic, and independent reading. Other points which have emerged, with reference to the V6 J5 petrol engine, are:

1.) The Mazda-recommended (instructed!) bleed method for the J5 engine takes longer than that for the WL-T diesel - perhaps unsurprisingly, given the two banked cylnder heads of the V6 (although we presumably don't know if there are air trapping areas at the top of them as in the WL-T's single head).

2.) When self-bled, the V6 seems* to take a lot longer to circulate entrapped air for eventual venting by topping up coolant at the ex tank - again perhaps not altogether surprisingly. I would therefore definitely not recommend it on a V6, at least not before there have perhaps been more guinea pigs.

*(Although my LPG conversion could possibly also be relevant here - coolant flows through parts of it. Anyway, be assured that I haven't deliberately self-bled my V6! It has been done by default, after a "Bongo-friendly" garage did not use the bleed (vent) hose method after a coolant change, and left me unwittingly completing a self-bleed process. I've been able to compare results/timing with another peep whose WL-T engine was given the same treatment at the same place.)
2001-V6-LPG-AFT-black on silver-Imperial Purbeck camper

(Ron miel=honey rum from the Canaries)
User avatar
dave_aber
Supreme Being
Posts: 2884
Joined: Tue May 12, 2009 4:33 pm
Location: Elgin, Scotland

Re: coolant flow - (follow up to cooling diagram)

Post by dave_aber » Thu Nov 18, 2010 11:08 am

Amazing what you can learn with a bit of Google.

According to Trouton's Rule, a liquid which boils at 109° when at 1Bar will boil at 112.37° at 1.1Bar.

However, it's occurred to me that my son's car has a 0.9 bar cap - what I take from this is that our 1.1bar caps mean that the actual boiling pressure is 1.1 bar above atmospheric - i.e. 2.1 Bar. At this pressure, the boiling point would be 136.9° for a liquid which boils at 109° when at atmospheric.
Image...Image
There are 10 types of people in this world.
Those that understand binary, and those that don't.
User avatar
haydn callow
Supreme Being
Posts: 5777
Joined: Mon Jan 08, 2007 9:50 pm
Location: Somerset
Contact:

Re: coolant flow - (follow up to cooling diagram)

Post by haydn callow » Thu Nov 18, 2010 11:22 am

isn't Atmospheric pressure 0 ??? at sea level
http://www.coolantalarm.co.uk
Developer of the Mazda Bongo Coolant loss Alarm
Also BMW Clocks
User avatar
Ron Miel
Supreme Being
Posts: 2239
Joined: Tue Oct 21, 2008 5:40 pm
Location: Cheshire

Re: coolant flow - (follow up to cooling diagram)

Post by Ron Miel » Thu Nov 18, 2010 11:44 am

That's a vacuum.
2001-V6-LPG-AFT-black on silver-Imperial Purbeck camper

(Ron miel=honey rum from the Canaries)
User avatar
dave_aber
Supreme Being
Posts: 2884
Joined: Tue May 12, 2009 4:33 pm
Location: Elgin, Scotland

Re: coolant flow - (follow up to cooling diagram)

Post by dave_aber » Thu Nov 18, 2010 11:54 am

No, atmospheric is 1Bar.

Tyre pressures, radiator caps, etc are usually measured as pressure compared to atmospheric - so a tyre at 1Bar is really at 1 Bar above atmospheric, i.e. 2Bar.


Absolute pressure and gauge pressure

Bourdon tube pressure gauges, vehicle tire gauges, and many other types of pressure gauges are zero referenced to atmospheric pressure, which means that they measure the pressure above atmospheric pressure (which is around 1 bar); this is gauge pressure and is often referred to as barg (spoken "bar gauge"). In contrast, absolute pressures are zero referenced to a complete vacuum and when expressed in bar are often referred to as bara. Thus, the absolute pressure of any system is the gauge pressure of the system plus atmospheric pressure. The usage of bara and barg is now deprecated, with qualification of the physical property being preferred, e.g., "The gauge pressure is 2.3 bar; the absolute pressure is 3.3 bar".[2]

In the United States, where pressures are still often expressed in pounds per square inch (symbol psi), gauge pressures are referred to as psig and absolute pressures are referred to as psia. Gauge pressure is also sometimes spelled as gage pressure.

Sometimes, the context in which the word pressure is used helps to identify it as meaning either the absolute or gauge pressure. However, in truth, whenever a pressure is expressed in any units (bar, Pa, psi, atm, etc.), it should be denoted in some manner as being either absolute or gauge pressure to avoid any possible misunderstanding. One recommended way of doing so is to spell out what is meant, for example as bar gauge or kPa absolute.[6]
Image...Image
There are 10 types of people in this world.
Those that understand binary, and those that don't.
User avatar
haydn callow
Supreme Being
Posts: 5777
Joined: Mon Jan 08, 2007 9:50 pm
Location: Somerset
Contact:

Re: coolant flow - (follow up to cooling diagram)

Post by haydn callow » Thu Nov 18, 2010 12:06 pm

Well there you go ....so my 1.1 bar pressure cap actually "blows" at 2.1 Bar
http://www.coolantalarm.co.uk
Developer of the Mazda Bongo Coolant loss Alarm
Also BMW Clocks
User avatar
dave_aber
Supreme Being
Posts: 2884
Joined: Tue May 12, 2009 4:33 pm
Location: Elgin, Scotland

Re: coolant flow - (follow up to cooling diagram)

Post by dave_aber » Thu Nov 18, 2010 12:24 pm

2.1 bara or 1.1barg.

The spring in it pushes at 1.1 bar. The air outside pushes at another 1 bar, so the water inside needs to push at 2.1 bar.
Image...Image
There are 10 types of people in this world.
Those that understand binary, and those that don't.
User avatar
widdowson2008
Supreme Being
Posts: 1703
Joined: Tue Nov 18, 2008 10:15 pm
Location: N.E.Derbyshire

Re: coolant flow - (follow up to cooling diagram)

Post by widdowson2008 » Thu Nov 18, 2010 12:58 pm

Getting back to subject of the topic, has anyone noticed something odd/different about these two flow paths?

This path goes from the block to the glow plug (very hot) to the inlet valve (not so hot) and out of the head through the main chamber.


This path goes from the block to the exhaust valve (very hot) to the inlet valve (not so hot) and out of the head through the main chamber.

Struck me that the designers could be trying to balance temperature of the two sides of the head in an attempt to reduce the temperature difference between the two. Why? To cut down the possibility of cracks due to thermal shock (Hot meets Cold)?
Steve
User avatar
dandywarhol
Supreme Being
Posts: 5446
Joined: Mon Dec 19, 2005 10:18 pm
Location: Edinburgh

Re: coolant flow - (follow up to cooling diagram)

Post by dandywarhol » Thu Nov 18, 2010 2:48 pm

Pressurised WATER boiling point is raised approx. 1.5 deg. C for every 1 psi of pressure - antifreeze mix raises the BP too
Whale oil beef hooked
Renault Lunar Telstar
Yamaha TD1C 250, Merc SLK200, KTM Duke 690
User avatar
dave_aber
Supreme Being
Posts: 2884
Joined: Tue May 12, 2009 4:33 pm
Location: Elgin, Scotland

Re: coolant flow - (follow up to cooling diagram)

Post by dave_aber » Thu Nov 18, 2010 3:09 pm

So (sorry Steve, I'm off on a tangent again), 1.1 Bar = 15.96psi equates to 23.25° increase. So, a 109° fluid would boil at 132.25°@1.1 Barg. Add a wee bit for the antifreeze, seems to correlate close enough to the web page I found earlier.


No wonder it hurts when you take the cap off still pressurised!
Image...Image
There are 10 types of people in this world.
Those that understand binary, and those that don't.
User avatar
mikexgough
Supreme Being
Posts: 6158
Joined: Mon Sep 08, 2008 9:02 pm
Location: Cambridgeshire - where the all the Slodgers reside
Contact:

Re: coolant flow - (follow up to cooling diagram)

Post by mikexgough » Thu Nov 18, 2010 3:56 pm

dave_aber wrote:So (sorry Steve, I'm off on a tangent again), 1.1 Bar = 15.96psi equates to 23.25° increase. So, a 109° fluid would boil at 132.25°@1.1 Barg. Add a wee bit for the antifreeze, seems to correlate close enough to the web page I found earlier.


No wonder it hurts when you take the cap off still pressurised!
Nice work dave...... so that raises the game a little for the "Green" corner.... so I guess the "red" corner would achieve similar results...... what interested me was from my chemist pal, he was saying that silicates in coolant leave a deposit on the waterways (bit like a film) over time and hot/cold cycles....leading to an "insulation" effect and the theory there is that hot spots could occur......

I have not found anyone to say exactly what causes the head failures on these Ford engines but if you put all the ideas together all the answer seems to be the correct maintanence.

The Truck guys (with the same engine)who have the overheating bothers all blame the coolant type and thermostat.....those with camshafts go blame their engine oils.....

I guess this whole process is an investigation as to how it all works in a Bongo/Freda, but at least we know the head crack issue is not Bongo/Freda specific .
Now Steve has produced all these diagrams, I guess a "review" is needed to put it all together.
Conversant with Bongo Top Pinion Oil Seals

Bongo owning Velotech Cycle Mechanic
User avatar
dandywarhol
Supreme Being
Posts: 5446
Joined: Mon Dec 19, 2005 10:18 pm
Location: Edinburgh

Re: coolant flow - (follow up to cooling diagram)

Post by dandywarhol » Thu Nov 18, 2010 5:15 pm

dave_aber wrote:So (sorry Steve, I'm off on a tangent again), 1.1 Bar = 15.96psi equates to 23.25° increase. So, a 109° fluid would boil at 132.25°@1.1 Barg. Add a wee bit for the antifreeze, seems to correlate close enough to the web page I found earlier.


No wonder it hurts when you take the cap off still pressurised!
Aye - this is what happened after a kettle of just of the boil water did - and that was a week after the event! 132 deg of sticky coolant is unimaginable :shock: I stupidly removed a cap off a Hillman Imp with a blown head gasket many moons ago and when I removed my soaked tee shirt all the skin on my arm and half of my chest came off with it - only 1st deg burn - Carole's wrist was 2nd degree!

Moral of story - let the pressure off first!

Whale oil beef hooked
Renault Lunar Telstar
Yamaha TD1C 250, Merc SLK200, KTM Duke 690
User avatar
dave_aber
Supreme Being
Posts: 2884
Joined: Tue May 12, 2009 4:33 pm
Location: Elgin, Scotland

Re: coolant flow - (follow up to cooling diagram)

Post by dave_aber » Thu Nov 18, 2010 5:22 pm

Ouch!

Almost as bad as Barrington's finger.
Image...Image
There are 10 types of people in this world.
Those that understand binary, and those that don't.
User avatar
widdowson2008
Supreme Being
Posts: 1703
Joined: Tue Nov 18, 2008 10:15 pm
Location: N.E.Derbyshire

Re: coolant flow - (follow up to cooling diagram)

Post by widdowson2008 » Fri Nov 19, 2010 9:44 am

2nd attempt
widdowson2008 wrote:Getting back to subject of the topic, has anyone noticed something odd/different about these two flow paths?

This path goes from the block to the glow plug (very hot) to the inlet valve (not so hot) and out of the head through the main chamber.


This path goes from the block to the exhaust valve (very hot) to the inlet valve (not so hot) and out of the head through the main chamber.

Struck me that the designers could be trying to balance temperature of the two sides of the head in an attempt to reduce the temperature difference between the two. Why? To cut down the possibility of cracks due to thermal shock (Hot meets Cold)?
Steve
User avatar
widdowson2008
Supreme Being
Posts: 1703
Joined: Tue Nov 18, 2008 10:15 pm
Location: N.E.Derbyshire

Re: coolant flow - (follow up to cooling diagram) BLEEDING

Post by widdowson2008 » Sat Nov 20, 2010 3:36 pm

Looks like the flows through the head has got others as baffled as me. (or possiblly not interested?)
So, I think the subject line, 'COOLANT FLOW' is exhausted. I'm pretty confident with what we have found out. Thanks for all your help.

Just leaves one area not discussed fully (based on known facts), and more to the point, I suspect one not totally understood by the majority of folk - me included. Seen it done but not fully understood what I was looking at.

I make no apologies for bringing up this old chestnut, (it is a major part of the cooling system) but I believe that knowledge to date has been based on guesswork and the 'I know better' attitude.
Personally, I need to understand how things work, not just take someone elses word for it.

What is the subject? BLEEDING.

Reason for bringing it up is that I think I may have a very simple solution to the black art (based on factual knowledge gained in this thread). Can't think how no one has thought of it before. (or perhaps they have)

I'LL BE BACK!!!
Steve
